Features
It is equipped with special pipeline.
It can continuously complete horizontal and vertical conveyance of concrete along pipeline.
It is an ideal kind of existing concrete conveyance equipment.
It combines the production of ready-mixed concrete with pumping construction and uses coagulation.
The soil mixing truck carries out intermediate operation, which can realize continuous pumping and pouring of concrete.
It is used for conveying concrete in large concrete projects.
Specification
| Item | Fine aggregate Concrete Pump | Diesel Concrete Pump | Drum type diesel and electric concrete pump |
| Max.conveying capacity | 25-40m3/h | 15-90m3/h | 30-80m3/h |
| Max.outlet pressure | 12 Mpa | Diesel engine 176 | 10Mpa |
| Max.aggregate size | ≤30mm | ≤30mm | ≤40mm |
| Motor power | 45KW | 80KW | 37KW |
| Max.horizontal delivery | 600m | 1600 | 800m |
| Max.vertical delivery | 180m | 350m | 400m |
| Borex Trip | Φ140*700mm | Φ140*1800mm | Φ180*1300mm |
| Conveying pipe inner diameter | Φ100(100)mm | Φ100(180)mm | Φ120(100)mm |
| Distribution valve type | S Valve | S Valve | S Valve |
| Dimension | 4500*1500*1700mm | 6000*2100*2260mm | 4200*1960*1800mm |
| Weight | 3000kg | 2800kg | 3000kg |
