Trailer concrete mixer truck

  • Mixing mechanism: the free mechanism, stirring according to the rotating movement of the mixing drum.
  • Low mobility:The machine is usually fixed in place or pulled at a close distance.

Description

  • 1.Mixing capacity: 2-10m3/batch .
  • 2.Mixing mechanism: the free mechanism, stirring according to the rotating movement of the mixing drum.
  • 3.Low mobility:The machine is usually fixed in place or pulled at a close distance.
  • 4.Specialized for mixing slurry, mortar and flexible concrete. Combined with trucks to transport concrete over long .
  • 5.Feeding: using an excavator .
  • 6.Discharding: concrete mixture is discharged by reversing the mixing tank.

Specification

Concrete mixer drum2m33m34m35m36m37m38m3
Geometric Volume3.7m35.3m36.4m38.6m39.7m310.3m311.8m3
Real volume2m33m33m35m36m37m38m3
Mixer Tank diameter1.5m1.72m1.9m2m2m2m2m
Slope12°12°18°18°18°18°18°
Tank length3300mm4400mm4500mm4990mm5110mm5400mm5700mm
Tank width1650mm2070mm2250mm2250mm2250mm2250mm2250mm
Tank height1750mm1990mm2380mm2550mm2550mm2550mm2550mm
Rotary speed0-10turns0-10turns0-10turns0-10turns0-10turns0-10turns0-10turns
